Good morning; I hope you had a great weekend. I apologize for not sending last week’s issue; I was feeling unwell and could not publish an issue for the week. In this issue, we will look into writing types with better type safety using Discriminated Unions and will have curated tweets and articles from the last two weeks.

I hope you have a great week ahead, and don’t forget to follow me on Twitter - @mwycliffe_dev and if you have any questions, ideas, or feedback, my DMs are open to everyone.

Better Type Safety with Discriminated Unions

If we want to get the most out of Typescript Types, we need to ensure that we are specific in how we define them. A loosely defined type might be better than not having them, but their impact will not be as good as having Types that properly reflect our data.

Let’s take the simplest example I can think of - Shapes. You get the idea in shapes; we can have Circles, Rectangles, Squares, etc. You cannot have a single type alias covering all shapes without compromising on something.

If we were to define a Shape type alias for just the above three shapes, it would need to account for the possibility that all fields are not there for all shapes, i.e., Circle only has a radius, which doesn’t exist in either Rectangle or Square, while the circle doesn’t have either width or height. As you can imagine, our problem becomes more extensive as you add more shapes.

So, our type alias would look like this.

type Shape = {

radius?: Number; // For Circle

length?: Number; // For Rectangle

width?: Number; // For Rectangle

side?: Number; // For Square side Length

}

From the above example, the type alias above is not very useful since if you had a circle, you could easily leave out all fields or add all of them to Shape and typescript will not be able to help you at all; all it can do is offer autocompletion hints for you.

And discriminated unions come to the rescue.

Discriminated Unions

Instead of defining a single type alias that loosely much all of our possible types, we can define three different types, each containing a literal field member indicating what shape we have.

For instance, the type for Rectangle would look like this:

type Rectangle = {

shape: "Rectangle",

length: number;

width: number;

}

And the same applies to both Circle and Square:

type Circle = {

shape: "Circle"

radius: number;

}

type Square = {

shape: "Square";

side: number;

}

And then, we can use a union of the three to declare a type alias of shape that can only be a single type of the above.

type Shape = Square | Rectangle | Circle;

Usage

Now, with our new Type shape, we have to indicate the shape field, and then typescript is going to use the shape field value to determine the fields that are required for the Type you are creating.

For instance, the shape Circle can only contain a radius property, and if you tried to add, let’s say, width, you will get an error:

const x: Shape = {

shape: "Circle",

radius: 5,

width: 5, // Error ---> Object literal may only specify known properties, and 'width' does not exist in type 'Circle'.

}

This offers a much better type safety as the shape field can now be strictly enforced depending on which you want, and you can now narrow the types based on the field shape.

if(shape.shape === "Circle") {

// the type is now a Circle only

}

This gives you peace of mind when using and creating objects compared to the loosely defined type we had initially.

I hope you found today’s lesson illuminating, and if you have any questions, please feel free to reach out to me.
